Technical equipment

hadivadlo_pudorys_small

The hall is in the style of the Black box with small stage on one side (3,5 m deep, 7 m wide, 1 m high, which can be entered from both sides on movable steps), barrier-free entrance to the hall, set-pieces can be brought by the lift (2.2 m x 0.9 m) or via staircase (1st floor).

the largest (optimum) stage space: 9 m (depth) x 10 m (width) with the capacity of 145 seats

the highest capacity: 200 seats (stage space 6 m x 10 m)

standing room for about 400 people

Height of the hall:   6.,5m
Length of the hall:   14 m
Width of the hall:   10 – 12 m (the hall narrows)
5 entrances to the hall

variable elevation (not movable platforms) (8 m wide, step height: 30 cm) – maximum 9 rows

Sandler chairs: 200 pieces

Apart from elevation there are:

12 pieces of movable platforms (2 m x 1 m, height adjustable: 20 cm, 40 cm, 60 cm, 80 cm, 100 cm)

2 pieces of movable platforms (1 m x 1 m, height 60 to 100 cm

Other equipment:

floor: black wooden, possibility of drilling

over the whole area of the hall there is a lighting grid, fly lines: 0

lights can be set from the movable lighting bridge

lighting bridges are on both sides of the hall

Lights:

svetla-small

Lighting console:

ETC 48/96, 24 submasters, 10 sides, programmable

DMX 1 – 512, 513 – 1024

Equipment:

FHR (PC) 1000 W: 35 pieces

FHR (PC) 500 W: 20 pieces

flaps

profile lights 1000 W, zoom 23 – 50, IRIS : 4 pieces

Follow spots 1200 W: 1 piece

Follow spots 1000 W: 1 piece

various tripods (1,5 m – 5m): 8 pieces

PAR lights 64: CP62: 6 pieces, CP61: 2 pieces

PAR lights 56: 12 pieces

floodlights 500 W: 6 pieces

floodlights 1000 W: 6 pieces

glass filters

hazer – Look Unique DMX, Mad DMX

Moving heads ROBE 575: 2 pieces

Video data projector: 1 piece

projection screen

Lights are hanging from the grid, on side bridges, above the stage and on the balcony. Movable lighting bridge for controlling lights and technical equipment in the grid.

Sound

Mix pult: ALLEIJ HEATH

loudspeaker boxes: Mackie SWA 1501 4 pieces

loudspeaker boxes: Mackie SMR 450 6 pieces

Effect Yamaha REV 100

Equaliser Zeck GF215 (2x 16)

2x MDS – JE700

CD Phillips

Cassette Deck Sony TCK 390

DVD Thomson (+ video)

microphone SHURE 580 – 4 pieces

microphone SHURE 570 – 2 pieces
